Arducam 13mp Mipi Camera Module With AR1335 CMOS Image Sensor
Specificaitons
| Sensor Type | 13MP AR1335 |
| Pixel Size | 1.1um x 1.1um |
| Resolution | 4160×3120 |
| Optical Size | 1/3″ |
| FOV(D) | 78.4° |
| F/NO | 2.0 |
| Focal Range | 10cm~Infinity |
| Focal Length | 3.57mm |
| TV Distortion | ＜-1.5% |
| Resolution | High Resolution |
Description
AR1335 is a 1/3.2-inch CMOS active-pixel digital image sensor with a pixel array of 4208H x 3120V. It features breakthrough 1.1µm pixel technology that delivers superior low-light image quality through leading sensitivity, quantum efficiency and linear full well. It is programmable through a simple two-wire serial interface and can generate full resolution image at up to 30 frames per second (fps) and supports advanced video modes including 4K 30fps, 1080P 60fps and 720P 120fps.
Features
◆13 Mp CMOS Sensor with Advanced 1.1 m Pixel BSI Technology
◆Data Interfaces: 2-, 3-, and 4-lane Serial Mobile Industry Processor Interface (MIPI)
◆Bit-depth Compression Available for MIPI Interface: 10-8 and 10-6 to Enable Lower Bandwidth Receivers for Full Frame Rate
Applications
◆3D Synchronization Controls to Enable Stereo Video Capture
◆6.8 kbits One-time Programmable Memory (OTPM) for Storing Shading Correction Coefficients and Module Information
◆Programmable Controls: Gain, Horizontal and Vertical Blanking, Auto Black Level Offset Correction, Frame Size/Rate, Exposure, Left-right and Top-bottom Image Reversal, Window Size, and Panning
◆Two On-die Phase-locked Loop (PLL) Oscillators for Super Low Noise
Performance
◆On-chip Temperature Sensor
◆Bayer Pattern Horizontal Down-size Scaler
◆Simple Two-wire Fast-mode + Serial Interface
◆Low Dark Current
◆Interlaced Multi-exposure Readout Enabling High Dynamic Range (HDR) Still and Video Applications
Applicaitons
Digital still cameras
PC cameras
IoT cameras
PDAs
