Wide Angle OV3660 ESP32 DVP Interface 24 Pin Camera Sensor Module
Specificaitons
| Image Sensor | OV3660 |
| FOV | 130° |
| Sensor | CMOS |
| Interface | DVP |
| Distortion | <-5% |
| Pixel | 3MP |
| Application | Industrial devices |
| Chip Type | OV Sensor |
| Special Feature | Face Recognition |
| Data Storage Options | SDK |
Description
This camera module from OV3660 is a high-resolution 3M pixels digital camera based on the ESP32 chip. It features an OV3660 image sensor and can capture photos and videos with a field of view of 130°. It’s ideal for taking high-quality photos and video monitoring.
Features
◆Design based on esp32
◆Ultra low power design
◆1.4 µm x 1.4 µm pixel with OmniBSI technology for high performance (high sensitivity, low crosstalk, low noise, improved quantum efficiency) ◆optical size of 1/5"
◆automatic image control functions: automatic exposure control (AEC), automatic white balance (AWB), automatic flicker detection, and automatic black level calibration (ABLC)
◆programmable controls for frame rate, AEC/AGC 16-zone size/position/weight control, mirror and flip, cropping, windowing, and panning
◆image quality controls: color saturation, hue, gamma, sharpness (edge enhancement), lens correction, defective pixel canceling, and noise canceling
◆support for output formats: RAW RGB, RGB565/555/444, CCIR656, YCbCr422, and compression
◆support for LED and flash strobe mode
◆support for horizontal and vertical sub-sampling, binning
◆support 2x2 binning with binning filter to minimize binning artifacts
◆support for data compression output
◆support for images sizes: 3 megapixel and any arbitrary size scaling down from 3 megapixel
◆suitable for modulesizeof6.5x6.5x
Applicaitons
Take Pictures Regularly
Remote Video Monitoring
