This is industrial-grade DVP HD OmniVision OV5640 sensor 5MP ESP32 camera module, with a 1/4-inch optical format and 1.4μm pixel architecture. Leveraging OmniBSI back-illuminated technology, it achieves enhanced low-light sensitivity while maintaining power consumption under 150mW across an extended operating temperature range. The fixed-focus lens delivers a 76.6° diagonal field of view with minimal distortion <1%, paired with F2.2 aperture for optimized light intake. Supporting DVP 24-pin parallel interface, the module enables 1080P HD video streaming alongside still image capture at 2592×1944 resolution. Integrated ISP functionalities provide auto exposure and white balance control, while COB packaging ensures vibration/humidity resilience for industrial deployments. Pre-tuned compatibility with ESP32 and other MCUs accelerates hardware integration for applications including drone navigation, smart access control, and automated inspection systems.
1. HD Imaging: 5MP sensor with 1.4μm pixels enhances light capture, enabling detailed 1080P video.
2. Extreme Environment Operation: OmniBSI + F2.2 aperture boosts low-light efficiency >40%, -30°C~70°C temperature tolerance.
3. Optical Precision: 76.6° wide-angle + 3.0mm focal length eliminates blind zones, optical distortion controlled within 1%.
4. Developer Efficiency: DVP interface with ESP32-tailored SDK accelerates development cycles by 30%, integrated ISP pipeline reduces secondary development.
| Product Name |
Micro 5MP ESP32 FPC Camera Module |
|
Sensor |
OV5640 Sensor |
| Piexl | 5MP |
|
F.NO |
2.2 |
|
Output Interface: |
DVP |
|
Sensor Size |
1/4 Inch |
|
Keywords |
CMOS Camera Module |
|
Warranty |
10 Years |
|
EFL |
3.3mm |
|
Brand Name |
SINCEREFIRST |
Ancient Book Restoration Monitoring: 1.4μm pixels in combination with a customized light source system achieve fiber-level tracking of paper changes and establish a digital archive of the restoration process
Smart Shelf: With a 3.0mm focal length, it can identify products within the range of 50cm to 3m and automatically detect out-of-stock or misaligned situations
Smart Door Lock: 5MP pixels provide 1080P high-definition video, quickly and accurately recognize faces, and automatically unlock the stored faces in combination with AI algorithms.
1. You can provide drawings or samples, as well as request documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.
Our products are sold all over the world, you can rest assured.
