Sony 4K Sensor IMX378 PDAF Night Vision MIPI Camera Module

Sony 4K Sensor IMX378 PDAF Night Vision MIPI Camera Module

Product Description:

This is the Sony 4K Sensor IMX378 PDAF Night Vision MIPI Camera Module, a universal professional optical imaging solution that combines high-definition imaging with stable performance. At its core lies the Sony IMX378 CMOS color image sensor, featuring a mature imaging architecture and comprehensive functional configuration. Detailed specifications are as follows: pixel resolution of 12MP, 1/2.3-inch sensor format, and a large pixel size of 1.55μm×1.55μm, enabling high-speed output of up to 4072×3064@60fps. Functionally, it supports PDAF phase-detection autofocus, Exmor RS™ stacked technology, and HDR high dynamic range to accurately handle complex imaging demands. Optically, it employs a professional M12×0.5P lens with a VCM motor for smooth autofocus, featuring an aperture of F3.6, focal length of 7.3mm, field of view covering D52°×H42.6°×V32.3°, and ultra-low optical distortion controlled at < -0.34%. Structurally, the module measures only 38mm×38mm×14.6mm, uses a 4Lane MIPI CSI-2 high-speed data interface, and is manufactured through COB die-bonding process combined with AA active alignment, ensuring product consistency and stability. The product has passed multiple international tests and certifications including CE, FCC, RoHS, and Reach.

Features:

1. Native UHD Imaging: 12MP native resolution paired with 1.55μm large pixels eliminates reliance on pixel-binning technology, directly outputting fine image quality that faithfully reproduces texture details of the subject.
2. Efficient Motion Capture: Supports up to 4072×3064@60fps high-speed output, with Exmor RS™ stacked technology enhancing signal processing efficiency to accurately capture fast-moving targets.
3. Low-Distortion Optics: OP distortion is strictly controlled at < -0.34%, accurately reproducing the dimensions and shape of subjects, avoiding measurement errors or visual deviations caused by distortion.
4. Industrial-Grade Quality: COB die-bonding process improves the module's anti-interference and heat dissipation performance, while AA active alignment ensures precise lens-to-sensor alignment, effectively guaranteeing batch-to-batch consistency and reducing defect rates.
5. Universal Standard Interface: Adopting the industry-standard 4Lane MIPI CSI-2 high-speed interface enables rapid integration with mainstream SoCs, simplifying development and adaptation processes, shortening product time-to-market, and improving launch efficiency.

Technical Parameters:

Applications:

• Intelligent Warehouse Sorting: Used for barcode recognition and package shape detection in warehouse environments. Low-distortion imaging ensures barcode reading accuracy, 60fps high-speed output matches the rapid pace of sorting lines, and the compact size allows integration into robotic arms or inspection units beside conveyor tracks.
• AI Agricultural Monitoring: Adapted for crop growth status monitoring and pest identification in greenhouse environments. The 1.55μm large pixel's low-light capability handles weak indoor lighting, HDR balances light-shadow differences within the greenhouse, and clear leaf detail capture supports precision agriculture management.
• Portable Outdoor Cameras: Employed for outdoor documentation in geological exploration and engineering surveying. Industrial-grade processes adapt to harsh field environments, compact size and lightweight design facilitate portability, and high-definition low-distortion imaging faithfully captures terrain and engineering details, providing reliable data for subsequent analysis.
• Motion Entertainment Devices: Integrated into AR/VR headsets, motion gaming consoles, or interactive advertising displays. Fast PDAF focusing and smooth 60fps video capture enable accurate gesture recognition, facial expression tracking, and immersive human-machine interaction experiences.

Customized Process:

1. You can provide drawings or samples, as well as request documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.
