Arducam OV7251 0.3MP Global Shutter Monochrome IR Sensitive Camera Module
Specificaitons
| Model | 0.3MP OV7251 |
| Sensor | 1/7.5’’ Omnivision OV7251 |
| Pixel | 0.3 Mega Pixel |
| Most Effective Pixels | 640(H) x 480(V), 320(H) x 240(V) |
| Pixel Size | 3.0µm x 3.0µm |
| Shutter Type | Global Shutter |
| RAW/SOC | Mono |
| Focus Type | Fixed Focus |
| FOV | 166° |
| Audio Frequency | Optional |
Description
Arducam now provides a low-cost high frame 0.3MP global shutter camera module based on OmniVision OV7251 black and white image sensor. The OV7251 is a small form factor, low power CameraChip™ sensor that uses a global shutter to reduce or eliminate unwanted image artifacts, which occur with traditional rolling shutter image sensors as a result of motion during image capture. The sensor’s global shutter and excellent low-light sensitivity allow it to be used for any application that has a need for gesture detection, head and eye tracking, and depth and motion detection.
Leveraging the industry’s smallest global shutter pixel, the black and white OV7251 is capable of capturing VGA (640×480) resolution video at 100 frames per second (fps), QVGA (320×240) at 180 fps with binning, and QQVGA (160×120) at 360 fps with binning and skipping. The OV7251’s high frame rates make it an ideal solution for low-latency machine vision applications.
Features
◆OV7251 monochrome 0.3 MP (640 x 480) global shutter sensor
◆1/7.5″ optical format
◆3 μm x 3 μm pixel size (1.968 mm x 1.488 mm sensor size)
◆F.NO: 2.0
◆FOV: 166°
◆Focusing Range: 5cm ~ infinity
◆Output interface: 1-lane MIPI serial output
◆Output format: Mono RAW
Applicaitons
Robot Camera
Machine Vision Camera
Industrial Camera
VSLAM Camera
Stereo Camera
