4.0mm Diameter VGA CMOS Sensor CVBS (AV/TV) Analog Output Endoscope Camera Module
Product Description:
This 4.0mm Diameter VGA CMOS Sensor CVBS (AV/TV) Analog Output Endoscope Camera Module is an industrial-grade analog imaging component specially designed for close-range visualization detection in narrow spaces, compliant with RoHS standards. Its probe diameter is precisely controlled at 4.0mm, an ultra-micro design that breaks through the space limitations of conventional detection equipment, enabling easy access to tiny spaces such as ultra-thin channels and narrow gaps that ordinary devices cannot reach, effectively expanding the detection range and applicable scenarios. The optical system is optimized for close-range endoscopic operations, featuring a 1.08mm focal length, F2.8 aperture, and 65° field of view, paired with a 30–80mm focusing range—this targeted optimization ensures enhanced clarity in close-range imaging, perfectly matching the typical working distance of endoscopic detection and meeting the needs of high-frequency inspection scenarios. With TV distortion strictly controlled within -1.5%, the module achieves true and accurate restoration of the geometric shape of the picture, significantly improving the credibility of observation results and the accuracy of judgment, which is crucial for precise detection tasks. Adopting CVBS (AV/TV) analog signal output, it can directly drive display devices for real-time observation without the need for additional digital processing units, simplifying the system structure, reducing deployment costs, and lowering the risk of equipment failure. The module is equipped with a 4PIN PAD interface (GND, VOUT, LED+, VCC), where VOUT is used for video signal output, and the LED+ and VCC pins support the optional installation of 4 0402 white light LEDs, which can effectively improve imaging quality in low-light narrow spaces. The image direction register adopts the factory default configuration, allowing entry into the standard working mode immediately after power-on without additional settings. Integrating micro size, analog direct output, low distortion, and close-range optimization, this module becomes a reliable imaging solution for industrial detection, automobile maintenance, precision electronics, and experimental exploration.
Features:
1.4.0mm Micro Diameter: The 4.0mm diameter allows penetration into tiny spaces inaccessible to conventional equipment, effectively expanding the detection range and applicable scenarios.
2.CVBS Analog Direct Output: It outputs standard analog video signals, which can be directly connected to display devices, simplifying the system structure and reducing deployment costs and failure risks.
3.30–80mm Close-Range Focusing: The focusing range is optimized for endoscopic working distances, enhancing close-range imaging clarity to meet the needs of high-frequency detection scenarios.
4.Low-Distortion True Imaging: With distortion < -1.5%, the geometric shape of the picture is accurately restored, improving the credibility of observation results and judgment accuracy.
Technical Parameters:
| Product Name |
VGA USB Camera Module |
| Sensor |
VGA |
| Focusing Range |
30~80mm |
| Focal Length |
1.08mm |
| F Number |
2.8 |
| FOV(D) |
65° |
| Output |
|
| TV Distortion |
<-1.5% |
| Basic Tolerance |
±0.1mm |
| Brand Name |
SINEREFIRST |
Applications:
1.Industrial Thin Pipe Endoscopy: It can be used to visually detect the inner wall status, defects and blockages of small-caliber pipelines (above 4mm); its 4.0mm diameter and low distortion ensure clear and accurate detection.
2.Automobile Hidden Part Maintenance: It can go deep into engine gaps, air conditioning pipelines and wiring harness clearances; its micro size enables non-disassembly, non-destructive fault location.
3.Precision Electronic Internal Observation: It is used for close-range inspection of solder joints, cables and components inside smart devices; its close-focus optimization assists in rapid fault troubleshooting.
4.Medical/Experimental Micro-Probe: It can be adapted to small cavities and experimental devices; its analog output facilitates real-time display and image recording of detection results.
