CMOS Sensor Face Recognition Wide Angle USB2.0 Interface Camera Module
Specificaitons
| AGC/AEC/White balance | AUTO |
| Max pixel rate | 28Mp/s |
| ADC accuracy | 10-bit |
| USB2.0 PHY | On Chip PHY |
| IR Filter | 650±10nm |
| Sensor Type | 1/3.75‘’ |
| Power system requirements | 70mA(VGA) |
| Power | USB bus power |
| Assembly technique | SMT(ROSH) |
| PCB printing ink | Green |
Description
High quality color photo imaging at QXGA resolution and video capability can be easily embedded into next generation low-powerlow-noise demands products with this new module SF302D. The camera module outputs image date with high speed USB 2.0 interface.With performance packaging technologyit achieved compacted size with high reliability of this module.It also features wide dynamic range by implementing high sensitivity and less noise.
.
Features
◆USB specification compliance
USB 2.0&1.1 compliance
USB video V1.1 compliance(UVC)
USB audio V1.0 compliance
USB high speedfull speed auto switching
USB 2.0 HS/FS PC Camera Controller
◆Supports QVGASVGAVGACIFQVGAand QCIF output formats.
◆USB Video Class compliantworks with native driver in Microsoft Windows XP
32-bit/64-bit,Windows 7 system and Windows 8 system
◆Auto Exposure(AE).
◆Auto White Balance(AWB).
◆Saturation Correction.
◆Color Correction.
◆Gamma Correction·
◆Gain Correction
◆Auto Edge enhancement.
◆Upgradeable partial firmware and customized parameters through USB interface
◆Software controlled connection to USB bus for re-enumeration
◆Adjustable and dynamic frame rate control on USB transaction
◆Automatic frame rate adjustment when exposure in low light environment
◆Selective suspend to minimize power consumption
Applicaitons
Vision inspection
Augmented reality
Document scanning
Head mount displays
Surveillance applications
Obstacle avoidance
Industrial automation
3D vision based assistance
