3.2 Inch Color Screen ESP32 Cam Camera Module ESP 32 Camera Development Board

3.2inch Color Screen Esp32 Cam Camera Module ESP 32 Camera Development Board

Product Description:

This LCD module uses ESP32-WROOM-32 module as the main control, the maincontrol is a dual-core MCU, integrated WI-FI and Bluetooth functions, the mainfrequency can reach 240MHz, 520KB SRAM, 448KB ROM, Flash size is 4MB, Thedisplay resolution is 240x320, resistive touch. The module includes LCD displayscreen, backlight control circuit, touch screen control circuit, speaker drive circuit,photosensitive circuit and RGB-LED control circuit. TF card interface, serial interface,temperature and humidity sensor interface (DHT11 interface) and reserved IO portinterface, this module supports development in arduino IDE, ESP IDE, Micropythonand Mixly.

Features:

• 3.2-inch color screen, support 16 BIT RGB 65K color display, display richcolors
• 240X320 resolution
• The sample program has been programmed in the factory and can beplugged in
• With TF card slot for easy expansion storage
• Provide arduino library functions and sample programs to facilitaterapid secondary development
• Support one-click download program
• Military-grade process standards, long-term stable work
• Support the lithium battery to be charged and discharged at the same time, with battery overcharge and discharge protection.

Technical Parameters:

Applications:

ESP32-CAM can be widely used in various IoT applications. It is suitable for home smart devices, industrial wireless control, wireless monitoring, QR wireless identification, wireless positioning system signals and other IoT applications. It is an ideal solution for IoT applications.
