Sony IMX676-AACR1 is a diagonal 10.04 mm (type 1/1.6) CMOS active pixel type solid-state image sensor with a square pixel array and 12.61M effective pixels. This chip operates with analog 3.3V, digital 1.1V, and interface 1.8V triple power supply. It has low power consumption.
The IMX676 MIPI camera module is an excellent choice for anyone looking for high-quality image capture capabilities. It offers a range of impressive features that make it a versatile and reliable option for a wide range of applications from industrial and medical imaging to security and surveillance systems.
One of the standout features of the IMX676 MIPI camera module is its outstanding image resolution. It is capable of capturing images at up to 4500 x 3000 pixels, offering exceptional detail and clarity. This level of resolution is ideal for applications where image quality is critical, such as in medical imaging or high-end industrial inspection systems.
Another benefit of the IMX676 MIPI camera module is its high-speed data transfer capabilities. It utilizes the MIPI interface standard, enabling fast and robust data communication between the camera and other devices. This results in efficient data transfer, reducing the likelihood of data corruption or loss.
The camera module is also designed with a small form factor, making it easy to integrate into various devices and applications. Its low power consumption also ensures that it does not put undue strain on the overall system, making it an efficient and reliable choice.
| Product Name | Sony IMX676 Camera Module |
| Lens Elements | 8G |
| EFL | 2.23MM |
| Pixel Array | 3536*3536 |
| F.No | 2.8 |
| Lens Type | ZJ3118-650-25 |
| View Angle | D:220 H:196 V:196 |
| Distortion | -7.1% |
| Focusing Range | 30cm-5M |
| Certification | Rohs, Reach, ISO |
| Pinout | 30pin |
Autonomous Driving
Uavs
Smart City
Medical Technology
Laboratory Automation
Robots
