Iris Recognition 1MP OV9281 Arducam Monochrome Global Shutter Camera Module
Specificaitons
| supply voltage | DC 5V±5% |
| Maximum Power consumption | 1200 mW |
| Operating system request | Win XP/win 7,8 / vista /android 4.0/ mac /Linux with uvc |
| Temperature (Operation) | -30°C to 70°C |
| Temperature (Stable Image) | 0°C to 50°C |
| S/N Ratio | 38 db |
| Max Dynamic Range | 68 db |
| F/No | 2.2 |
| EFL | 2.1mm |
| FOV | 100° |
Description
The Arducam OV9281 camera breakout incorporates Omnivision 1/4-inch 1 Mp (1280×800) CMOS digital image sensor which is capable of operating at up to 60fps in 1MP ( 1280×800 ) resolution at 1-lane MIPI mode. The OV9281's high frame rates make it an ideal solution for low-latency machine vision applications.
Features
◆Sensor: Monochrome global shutter OV9281
◆Pixel Size: 3 μm x 3 μm
◆Active array size: 1280 x 800
◆Optical Size: 1/4 inch
◆Focusing Range: 65mm ~ infinity
◆IR Sensitive: 850±10nm
◆Output formats: YUY2/MJPEG
SCCB control interface for register programming
Applicaitons
augmented reality (AR)
virtual reality (VR)
collision avoidance in drones
bar code scanning and factory automation
