720P OV9734 3.6mm Ent Endoscopy Treatment Endoscope Camera Module Review
Specificaitons
| Resolution |
720P Max 30fps |
| LED | 0402 LED |
| Image Device | 1/9" inch |
| Lens | DFOV95 |
| TV Distortion | <-10% |
| Diameter | 3.6mm |
| Active array size | 1280 x 720 |
| operating | -30°C to 85°C junction temperature |
| core | 1.2VDC ± 5% |
| I/O | 1.8V |
Description
This is our popular endoscope camera module, it is 1MP resolution with Omnivision OV9734 sensor, and it supports 30FPS high frame rate at 720P resolution.This camera module is very small, you can almost fit it within any of your device/equipment, no matter how small the space is.There are 4 built-in LED lights, you can use this camera module both in daytime or night time, even without light at all. We can either provide you the camera module only, or we can provide you camera module with casing.
Features
◆Auto Focus
◆1MP resolution with Omnivision OV9732 image sensor
◆It supports 30FPS high frame rate at 720P
◆Module size is very small
◆Night vision is supported with built-in LED ring
◆USB interface + Android interface
◆UVC compliant, Plug & Play
◆Support Linux, Android, Mac and Windows
◆Casing is supported
Applicaitons
medical
industrial
ears
nose
mouth
throat
teeth
Our products are sold all over the world, you can rest assured.
