High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module

High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module

Products - USB Camera Module
  • Highlight

    High Sensitivity USB3.0 Camera Module

    ,

    USB3.0 Camera Module

    ,

    HDR USB3.0 Camera Module

  • Product Name
    12 Megapixel Color Camera Module
  • Drive Mode
    Free Diver
  • Photosensitive Type
    Sony IMX577 CMOS
  • Pixel Size
    1.55μmX1.55μm
  • Photosensitive Size
    1/2.3"
  • Imaging Distance
    1CM~∞
  • Standard Configuration
    USB3.0 High Speed
  • Working Current
    300mA(VGA)
  • Operating Voltage
    USB-DC5V
  • Output Forma
    MJPG/YUY2
  • Place of Origin
    Guangdong , China
  • Brand Name
    SINCERE FIRST
  • Certification
    Rohs, Reach, ISO
  • Model Number
    SF13A886 USB3.0
  • Minimum Order Quantity
    5 pcs
  • Price
    Negotiable
  • Packaging Details
    Package, Carton Box
  • Delivery Time
    7 - 15 Work Days
  • Payment Terms
    L/C, Western Union, T/T, MoneyGram, Paypal and Others
  • Supply Ability
    350000 pcs / month

High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module

  • High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module
  • High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module
  • High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module
  • High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module
Get Price Contact Now

High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module

Product Description:

Product Overview - HD IMX577 12MP Color USB Camera Module

This is our new USB3.0 high speed color camera module development, it is 12MP (4000x3000) resolution with SONY IMX577 CMOS sensor, image quality is excellent; it features High Dynamic Range & High sensitivity; All these features make our camera module very rare and unique in the market.



It supports the below resolution & frame rate:

MJPG:

4000x3000@9FPS; 3840x2160@27FPS; 2592x1944@27FPS; 2688x1512@27FPS; 2048x1536@27FPS; 1920x1080@27FPS; 1600x1200@27FPS; 1280x960@27FPS; 1280x720@27FPS; 960x540@27FPS; 800x600@27FPS; 640x480@27FPS; 640x360@27FPS;

YUY2:

1920x1080@27FPS; 1280x720@27FPS; 800x600@27FPS; 640x480@27FPS;

Features:

  • USB3.0 Interface
    2. 12MP resolution with SONY IMX577 CMOS sensor
    3. UVC compliant, Plug & Play
    4. Support Linux, Android, Mac and Windows
    5. High Dynamic Range & High sensitivity

Technical Parameters:

Technical Parameters Value
Drive-free Agreement USB Video Class (UVC)
Module Size 38mmX38mm
Drive Mode Free Diver
Operating Voltage USB-DC5V
Operating System Windows, Android, MAC-ios, Linux
Pixel Size 1.55μmX1.55μm
Standard Interface USB3.0 High Speed
Photosensitive Size 1/2.3"
Imaging Distance 1CM~∞
Operating Current 300mA(VGA)
Key Features USB camera board, CMOS camera module, camera sensor


Applications:

This camera module is widely used for high-tech and high-demanding applications like security, robotics, artificial intelligence(AI), machine vision, computer vison, IoT, surveillance, educational equipment, medical imaging, embedded devices, industrial automation, traffic monitoring system, agritech, video meeting, etc.

High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module 0
High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module 1High Sensitivity 12MP Sony IMX577 CMOS Sensor HDR USB3.0 Camera Module 2
