1. High sensitivity, low voltage, suitable for embedded applications.
2. Standard SCCB interface, compatible with I2C interface.
3. Supports automatic exposure control, automatic reinforcement control, automatic white balance, automatic elimination of light strips, automatic black level calibration.
4. Supports image zoom, swivel and window settings.
5. Support image compression, you can output JPEG image data.
6. comes with embedded micro processor.
| Product Name | OV5640 Camera Module |
|---|---|
| Image Sensor | 1/4’’ OV5640 |
| Pixel Size | 1.4um(H) x 1.4um(V) |
| Interface | 24pin DVP |
| Focus Type | Fixed Focus |
| View Angle | 150° |
| Shutter Type | Electronic Rolling Shutter |
| Resolution |
5Megapixel 2592H x 1944V |
| EFL | 3.29 |
| TV Distortion | ＜1% |
