Micro 0.9mm Endoscope Camera Module For Medical Industrial Application

Micro 0.9mm Endoscope Camera Module For Medical Industrial Application

Products - Endoscope Camera Module
  • Highlight

    Industrial Application Endoscope Camera Module

    ,

    Micro Endoscope Camera Module

    ,

    0.9mm Endoscope Camera Module

  • Features
    Smallest
  • Image Sensor
    OCHTA10
  • Pixel Size
    400(H)*400(V)
  • View Angle
    120°±6°
  • Interface Type
    Type-C
  • Applications
    Medical
  • Diameter
    0.9mm
  • Product Name
    Endoscope Camera Module
  • Warranty
    10 Years
  • Replacement
    1 Year
  • Place of Origin
    Guangdong , China
  • Brand Name
    SINCERE FIRST
  • Certification
    CE, FCC, RoHS, REACH, ISO
  • Model Number
    SF-TA10USB-D0.9
  • Minimum Order Quantity
    5 pcs
  • Price
    Negotiable
  • Packaging Details
    Package, Carton Box
  • Delivery Time
    7 - 15 Work Days
  • Payment Terms
    L/C, Western Union, T/T, MoneyGram, Paypal and Others
  • Supply Ability
    350000 pcs / month

Micro 0.9mm Endoscope Camera Module For Medical Industrial Application

  • Micro 0.9mm Endoscope Camera Module For Medical Industrial Application
  • Micro 0.9mm Endoscope Camera Module For Medical Industrial Application
  • Micro 0.9mm Endoscope Camera Module For Medical Industrial Application
  • Micro 0.9mm Endoscope Camera Module For Medical Industrial Application
Get Price Contact Now

Micro 0.9mm Endoscope Camera Module For Medical Industrial Application

Product Description:

This MINI endoscope camera module uses a CMOS OCHTA10 sensor with a resolution of 400*400. The endoscope camera module has an outer diameter of 0.9mm without LEDs. The FOV (diagonal) is 120 degrees and the depth of field is 3-100 mm.

Technical Parameters:

Pixel Size 1.4umX1.4um
USB Protocol USB2.0HS/FS
Lens Size 1/9 Inch
Maximum Effective Pixel 1280(H)X720(V)
Sensitivity 600mV/Lux-sec
Output Format Standard UVC
Sensor CMOS Sensor
Image Region 1972μm X 1008μm
Interface Type USB2.0 High Speed
Output Image Format YUV2(YUYV)/ MJPEG


Applications:

Pipeline Inspection

Medical Equipment

Industrial Cameras
