OCHTA10 1.2mm Diameter Ultra-Compact Sensor Industrial Medical High-Definition Endoscope Camera Module

OCHTA10  1.2mm Diameter Ultra-Compact Sensor Industrial Medical High-Definition Endoscope Camera Module

Product Description:

This is an ultra-compact USB endoscope camera module featuring an OCHTA10 sensor with 400×400 resolution and a 100°×100° ultra-wide field of view. It supports a 3-30mm focus range with image distortion below 11%. The module integrates a USB 2.0 UVC interface for plug-and-play compatibility across multiple systems. It supports dual output formats is YUV/MJPEG and features a compact design, making it ideal for high-definition imaging in confined spaces such as industrial inspection and medical observation.

Features:

1. Ultra-Micro Panoramic Imaging: With 400×400 resolution, an OCHTA10 sensor, and a dual-axis field of view of 100°×100°, it achieves both high resolution and a large field of view within an extremely compact 1.2mm footprint. This enables it to capture minute structures while maintaining a wide observation range, making it ideal for panoramic inspection in complex spaces such as pipe interiors and precision assemblies.
2. True-Distance Low Distortion: 3-30mm wide-range focusing, F2.8 aperture, and < -11% distortion enable detailed close-up observation at 3mm while covering mid-range scenes up to 30mm. Paired with low-distortion optical design, it ensures true, undistorted clear images across varying working distances.
3. Smart Driverless Compatibility: USB 2.0 UVC protocol, dual YUV/MJPEG formats, and multi-system compatibility enable direct use on Windows/Android/Linux systems without driver installation. Dual output formats meet diverse needs for real-time streaming and high-quality image processing, significantly lowering development and usage barriers.

Technical Parameters:

Applications:

Medical

Industrial

Customized Process:

1. You can provide drawings or samples, as well as request documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.

About US:

Cooperative Brands & Customers:

Why Chooes US:

Details Pictures:
