IMX219 CMOS Sensor YUV Output MIPI CSI-2 Interface Auto Focus Camera Module
Product Description:
The IMX219 CMOS Sensor YUV Output MIPI CSI-2 Interface Auto Focus Camera Module,is engineered to eliminate complex development barriers while delivering consistent, application-ready imaging performance. Leveraging the battle-tested IMX219 sensor paired with a calibrated autofocus optical system, it optimizes the 2.92mm focal length, F2.4 aperture and 75° diagonal field of view to balance light sensitivity and viewing coverage, ensuring crisp visuals across varied ambient conditions; the 10cm to infinity continuous focusing range eliminates manual adjustment hassles, catering to both micro-detail inspection and wide-scene monitoring, with TV distortion restrained below 1% to deliver geometrically accurate images that require no post-processing correction for measurement or recognition tasks. Supporting standard YUV output and governed by universal MIPI CSI-2 and I2C interfaces for plug-and-play configuration, it features a space-smart integrated FPC and structural design, fully adheres to RoHS environmental directives, and stands as a low-risk, high-reliability imaging choice for developers and manufacturers targeting rapid prototyping and large-scale volume production.
Features:
1.Hassle-Free Cross-Scene Focusing: Designed with a wide 10cm to infinity focusing span, this module adapts instantly between close-quarters macro capture and long-distance scene imaging, with zero manual focusing required. It maintains stable focus clarity during dynamic scene shifts, making it ideal for devices that need to handle both near-field detection and full-range observation without hardware or parameter modifications.
2.Calibrated Low-Distortion Fidelity: Factory-calibrated to keep TV distortion under 1%, this module delivers edge-to-edge consistent imagery with zero geometric distortion, enabling direct use in precision positioning, visual recognition and measurement applications without additional algorithmic correction. This pre-calibrated performance cuts down development time and ensures uniform imaging quality across every production unit.
3.Universal Embedded Compatibility: Equipped with standard MIPI CSI-2 and I2C interfaces, this module seamlessly pairs with mainstream embedded development platforms, single-board computers and custom control boards. It bypasses complicated driver development and tedious debugging, shortening project cycles and lowering integration costs for both prototype testing and mass manufacturing.
4.Compact & Mass-Production Robust: Featuring a slim, integrated form factor with unified FPC and structural components, it fits effortlessly into space-constrained enclosures for compact devices. The ruggedized design ensures consistent performance under long-term operation, while RoHS compliance and tight unit-to-unit consistency make it perfectly suited for high-volume, commercial-grade production runs.
Technical Parameters:
| Product Name |
MIPI Camera Module
|
|
Sensor
|
IMX219 CMOS
|
| Focusing Rangle |
10cm-infinity |
|
F.NO
|
2.4
|
|
Output Interface
|
MIPI |
|
Focus Distance
|
2.92mm
|
|
Keywords
|
MIPI Camera Module
|
|
Warranty
|
10 Years
|
|
Distortion
|
<1%
|
|
Brand Name
|
SINCEREFIRST
|
Applications:
- Smart Home: The large-pixel advantage allows the camera to clearly recognize the activity status of family members at nighttime or in low-light conditions; the wide FOV can cover a larger indoor area, and a single device can monitor the entire room; the compact design facilitates concealed integration into home products, maintaining aesthetics without sacrificing performance.
- VR/AR: The 120FPS high frame rate combined with the global shutter can accurately capture fast hand movements and head rotations, providing smooth, blur-free visual data; the excellent near-infrared response characteristics support cooperation with infrared markers to achieve high-precision spatial positioning and motion tracking, enhancing the realism of immersive experiences.
- AOI Inspection: At a 2m/s board conveying speed on SMT production lines, the global shutter freezes images of solder joints and components; the 3μm pixel resolution meets the inspection requirements for 01005 components; NIR illumination suppresses reflection interference from pads; the 10-Bit RAW data supports deep learning models in identifying hidden defects such as microcracks and cold solder joints.
Customized Process:
1. You can provide drawings or samples, as well as request documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.
