A side view is useful only when light reaches the surface being examined. This triple-lens camera places illumination at all three viewing positions: eight white LEDs at the front and one beside each side-view camera.
The arrangement is suited to inspection tools that examine both forward-facing and lateral surfaces inside an enclosure. Evaluate each view against the actual wall distance and surface reflectivity to select the right lighting configuration.
1. Lighting for each viewing direction: The 8 + 1 + 1 LED arrangement supplies light at the front and both side cameras.
2. Inspection around the camera head: One front camera and two side cameras provide different perspectives on internal surfaces.
3. Integrated steel assembly: The cameras and LEDs share a 7.9mm head, simplifying the layout of a probe with multiple viewing directions.
4. Protected head for enclosed inspection: The IP67 head is relevant where dust or water may reach the probe during use.
|
1. Housing inspection probes: Examine inner walls and forward-facing features where external light cannot reach.
2. Pipe wall inspection tools: Use side-mounted illumination to view surfaces beside the probe.
3. Machinery maintenance cameras: Inspect recessed components through a service opening with local illumination.
4. Metal cavity inspection systems: Evaluate internal surfaces while checking glare and reflections at the working distance.
1. You can provide drawings or samples, as well as request documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.
Our products are sold all over the world, you can rest assured.
