For a portable inspection tool built around a phone or tablet, the host connection is part of the product design. This dual-lens camera supports Android and iOS systems and combines forward and side observation for on-site inspection.
The front camera focuses at 5cm and the side camera at 4cm, addressing different viewing positions inside a cavity. Confirm the intended device, connector arrangement and viewing application before sampling so the camera fits the complete mobile workflow.
1. Android and iOS support: Provides a camera option for inspection products using either mobile platform. Compatibility should be checked with the intended hardware and application.
2. Forward and lateral observation: Two viewing directions help an operator inspect the route ahead and surfaces beside the probe.
3. Focus matched to each view: The front and side cameras have specified focus distances of 5cm and 4cm respectively.
4. Local lighting for mobile inspection: Eight front LEDs and one side LED illuminate enclosed targets without relying on room light.
| Product Name | USB2.0 Endoscope Camera Module |
| Model | SF-SPIOS55-2A09 |
| Sensor | CMOS |
| Pixel | 1MP |
| Resolution | 1280 × 720 |
| Video Output | 720P@18fps |
| Output Interface | USB2.0 |
| Sensor Size | 1/9 inch |
| Pixel Size | 1.4µm × 1.4µm |
| Focus Type | Manual Focus |
| Focus Distance | Front: 5cm; side: 4cm |
| Field of View | D78° |
| Aperture | F2.8 |
| Camera Configuration | 1 front-view camera + 1 side-view camera |
| Camera Head Diameter | 7.9mm |
| Camera Head Housing | Steel sleeve |
| Protection Rating | IP67 camera head |
| LED Configuration | 8 front LEDs + 1 side LED; white SMD |
| Supported Systems | Android and iOS |
| Brand Name | SINCEREFIRST |
1. Phone-based service inspection tools: Use a mobile device as the viewing interface during equipment checks.
2. Tablet inspection kits: Provide front and side observation for teams using tablets at the work site.
3. Building cavity inspection devices: Examine accessible enclosed areas where a mobile display is convenient.
4. Portable maintenance probes: Inspect recessed surfaces during field servicing with the supported mobile host.
1. Specify the Android or iOS device, connector and intended viewing application.
2. Review the access opening, front and side target distances, and cable requirements.
3. Confirm the sample connection arrangement.
4. Validate image display, camera selection and operation on the intended mobile device.
5. Approve the complete camera-to-host configuration before production.
