The access opening can determine camera selection before image specifications do. With a 6.35mm steel head, this single-camera module is an option for inspection tools that need to enter spaces too restricted for a larger probe.
The integrated lens and six white LEDs support close-range observation at a specified 5cm focus distance. Choose it when the task needs one direct view and access clearance is the main constraint.
1. A smaller entry diameter: The 6.35mm head provides an alternative to the 7.9mm multi-camera models when opening size limits access.
2. One direct inspection view: A single-camera design fits tasks where the target can be viewed along the insertion direction.
3. Illumination integrated with the lens: Six white SMD LEDs light the target inside a dark cavity.
4. Steel head with IP67 protection: The camera head supports use where dust or water may be present; USB2.0 provides the host connection.
|
1. Small access-hole inspection tools: Reach internal areas through openings that accommodate the head with adequate clearance.
2. Compact equipment service probes: View recessed parts when the available insertion path is narrow.
3. Enclosed product inspection fixtures: Position the camera through a defined opening to check an internal target.
4. Narrow passage viewers: Observe ahead of the probe where a single viewing direction meets the task.
1. Provide the minimum opening size and the shape of the insertion path.
2. Check the target position and available distance against the optical configuration.
3. Review the cable route, sealing needs and USB host.
4. Test insertion, image clarity and LED reflections in the actual assembly.
5. Approve the sample configuration before production.
