0.3mp OV Camera Optical Sensor Image OV7251 Camera Module Company
Specificaitons
| Image Sensor | OV7251 |
| Optical Format | 1/7.5” |
| Resolution | 640x480 |
| Pixel Size | 3.0 µm |
| Shutter Type | Global |
| Interface | MIPI |
| View Angle | H=56.8°/V=44°/D=77° |
| Focus Range | 8cm~infinity |
| Distortion | ＜1% |
| Pinout | 30pin |
Description
OV7251 is a small form factor, low power CameraChip™ sensor that uses a global shutter to reduce or eliminate unwanted image artifacts, which occur with traditional rolling shutter image sensors as a result of motion during image capture. The OV7251 is capable of capturing VGA (640x480) resolution video at 120 frames per second (fps), QVGA (320x240) at 180 fps with binning, and QQVGA (160x120) at 360 fps with binning and skipping.
Features
Resolution: 640×480
Optical size: 1/7.5″
FOV: H=56.8° V=44° D=77°
Pixel size: 3um x 3um
Maximum frame rate: 100fps
Output formats: 10-bit B&W RAW
Output interface: 1-lane MIPI
Applicaitons
Robot Camera
Machine Vision Camera
Industrial Camera
VSLAM Camera
Stereo Camera
