High Resolution Camera Image Processing Sensor USB Camera Module Design
Specificaitons
| Module Pixel | 8Mega Sensor |
| Sensor Type | CMOS Sensor |
| Module Head Size | 61.1mm(L)*10.0mm(W)*6.0mm(H) |
| AGC/AEC/WhiteBalance | Automatic Control |
| Power Source | Uses USB BUS Power |
| Focus Mode | Fixed Focus |
| DSP | Uses the high performance digital processing chip |
| Interface | USB2.0 |
| Focus range | 10cm to Infinity |
| Fov(D) | 72° |
Description
The USB camera module is a general-purpose camera control board designed for both PCs and embedded systems like the ARM, Raspberry Pi, Odroid, and similar hardware.
Features
◆1/3.2 inch Coms USB Camera Module
◆8Mega Cmos Sensor USB Camera Module
◆USB webcam with UVC, support Windows, Linux, Mac with UVC and Android system.
◆USB Camera Module with 72 degree
◆61*10mm micro USB board camera
Applicaitons
AI
Machine Vision
Inspection tester
Video Conference System
